| Specifications |
|
|
|
| Product Attribute |
Attribute Value |
| Manufacturer: |
MEAN WELL |
| Product Category: |
AC/DC Power Modules |
| RoHS: |
YES |
| Output Power: |
15 W |
| Input Voltage: |
80 VAC to 264 VAC |
| Number of Outputs: |
1 Output |
| Output Voltage-Channel 1: |
12 VDC |
| Output Current-Channel 1: |
1.25 A |
| Length: |
49 mm |
| Width: |
23.8 mm |
| Height: |
23 mm |
| Industry: |
Medical |
| Approvals: |
ES60601-1, IEC/EN60601-1 |
| Brand: |
MEAN WELL |
| Input Frequency: |
47 Hz to 440 Hz |
| Isolation Voltage: |
4 kVAC |
| Load Regulation: |
Regulated |
| Maximum Operating Temperature: |
+ 85 C |
| Minimum Operating Temperature: |
- 35 C |
| Mounting Style: |
PCB |
| Open Frame/Enclosed: |
Open Frame |
| Product Type: |
AC-DC Power Modules |
| Factory Pack Quantity: |
200 |
| Unit Weight: |
1 oz |
